GLOSSARY OF SYMBOLS
To promote uniformity of interpretation,the following symbols and definitions are employed where applicable in presenting formulas in the individual monographs.[NOTE—Where the terms Wand t both appear in the same equation they must be expressed in the same units.]
a relative retention,
Click to View Image
cR,cI,cU concentrations of Reference Standard,internal standard,and analyte in a particular solution.
CA concentration ratio of analyte and internal standard in test solution or Assay preparation,
Click to View Image
CS concentration ratio of Reference Standard and internal standard in Standard solution,
Click to View Image
f distance from the peak maximum to the leading edge of the peak,the distance being measured at a point 5%of the peak height from the baseline.
k¢ capacity factor,
Click to View Image
Click to View Image
N number of theoretical plates in a chromatographic column,
Click to View Image
qR,qI,qU total quantities (weights)of Reference
Standard,internal standard,and analyte in
a particular solution.
QA quantity ratio of analyte and internal standard in test solution or Assay preparation,
Click to View Image
QS quantity ratio of Reference Standard and
internal standard in Standard solution,
Click to View Image
rS peak response of the Reference Standard obtained from a chromatogram.
rU peak response of the analyte obtained from a chromatogram.
R resolution between two chromatographic peaks,
Click to View Image
RF chromatographic retardation factor equal to the ratio of the distance from the origin to the center of a zone divided by the distance from the origin to the solvent front.
RR relative retention
Click to View Image
RR relative retention time
Click to View Image
RS peak response ratio for Standard preparation containing Reference Standard and internal standard,
Click to View Image
RU peak response ratio for Assay preparation containing the analyte and internal standard,
Click to View Image
SR(%) relative standard deviation in percentage,
Click to View Image
where Xiis an individual measurement in a set of Nmeasurements and Xis the arithmetic mean of the set.
T tailing factor,
Click to View Image
t retention time measured from time of injection to time of elution of peak maximum.
ta retention time of nonretarded component,air with thermal conductivity detection.
W width of peak measured by extrapolating the relatively straight sides to the baseline.
Wh/2 width of peak at half height.
W0.05 width of peak at 5%height.
